7-1-10 Torque Bias Monitor [d010]
Use this function to display the current torque bias value under sensorless vector control.
The torque bias monitor function estimates the torque value equivalent to the rated current of the
inverter as 100%.
To convert it to the rated motor torque ratio, use the following formula:
Rated motor torque ratio = Monitor value  Rated output current of inverter / Rated motor current
For details on the torque bias monitor function, refer to 6-4-2 Torque Bias Function Settings on page
6-17.
Parameter
No.
Function name
Data
Default
data
Unit
d010
Torque Bias Monitor
−200. to 200.
−
%
Related functions
A044, A244, P036, P037, P038
7-1-11 Output Torque Monitor [d012]
Use this function to display the estimated output torque value of the inverter.
The value is displayed only when sensorless vector control is selected.
The output torque monitor function estimates the torque value equivalent to the rated current of the
inverter as 100%.
To convert it to the rated motor torque ratio, use the following formula:
Rated motor torque ratio = Monitor value  Rated output current of inverter / Rated motor current
Parameter
No.
Function name
Data
Default
data
Unit
d012
Output Torque Monitor
−200. to 200.
−
%
Related functions
A044, A244
Note During forward RUN, the value is positive for Power Running and negative for Regeneration. During
reverse RUN, the value is negative for Power Running and positive for Regeneration.
7-1-12 Output Voltage Monitor [d013]
Use this function to display the output voltage of the inverter.
Parameter
No.
Function name
Data
Default
data
Unit
d013
Output Voltage
Monitor
0.0 to 600.0
−
V
Precautions for Correct Use
Set the 1st/2nd Motor Rated Voltage Selection (A082/A282) correctly. Otherwise, the correct
value may not be displayed.

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
