Omron MX2 Series User Manual

Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Manual Structure
3
Manual Structure
Page Structure and Symbol Icons
The following page structure and symbol icons are used in this manual.
Level 2 heading
Level 1 heading
Level 2 heading
Section Level 1
Level 3 heading
Level 3 heading
Operation Steps
Describes the operation
steps.
2
Note, Supplementary
Information, Reference
Target
A note, supplementary
information, reference
target, etc. are provided
with difference icons.
Manual Name
Note The above page is only a sample for illustrative purposes. It is not the actual content of the manual.

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
