Omron MX2 Series User Manual

12 Options
12 - 7
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
12-4 EtherCAT Communications Unit
(Model: 3G3AX-MX2-ECT)
12-13-1 Specifications
Item
Specifications
General
specifications
Power supply
Supplied from inverter
Enclosure rating
IP20
Operating ambient
temperature
−10 to 50°C
Storage ambient
temperature
−20 to 65°C
Operating ambient
humidity
20% to 90% (with no condensation)
Vibration resistance
5.9 m/s
2
(0.6 G), 10 to 55 Hz
Location
At a maximum altitude of 1,000 m, indoors (without corrosive
gases or dust)
Weight
100 g max. (Shipping weight: Approx. 130g)
EC Directives
EMC Directive: EN61800-3
Low Voltage Directive: EN61800-5-1
UL/cUL Standard
UL 508C
EtherCAT
Communication
specifications
Communications
standard
IEC 61158 Type12, IEC 61800-7 CiA 402 drive profile
Physical layer
100BASE-TX (IEEE802.3)
Connector
RJ45  2 (shielded type)
ECAT IN: EtherCAT input
ECAT OUT: EtherCAT output
Communications media
Category 5 or higher (cable with double, aluminum tape and
braided shielding) is recommended.
Communications
distance
Distance between nodes: 100 m max.
Process data
Fixed PDO mapping
PDO mapping
Mailbox (CoE)
Emergency messages, SDO requests, SDO responses, and SDO
information
Distributed clock
Free-run mode (asynchronous)
LED display
L/A IN (Link/Activity IN)  1
L/A OUT (Link/Activity OUT)  1
RUN  1
ERR  1
CiA402 drive profile
Velocity mode
12
12-13 EtherCAT Communications Unit (Model:
3G3AX-MX2-ECT)
12-13-1 Specifications

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
