Omron MX2 Series User Manual

8 Communications Functions
8 - 37
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
8-9 Modbus Communication Data Lists
R/W in the list shows whether data can be read from, or written to, the coil or holding register.
(R: Read only, R/W: Read and write enabled)
Precautions for Correct Use
• The “Coil No.” in the table header shows the coil number used inside the inverter.
Use this coil number when setting EtherCAT communications.
• The “Modbus coil spec. No.” in the table header shows the coil number used to actually spec-
ify the coil in the Modbus communication process.
This coil number is 1 less than the inverter “Coil No.” according to the Modbus communica-
tion specifications.
8-9-1 Coil Number List
Coil No.
Modbus coil
spec. No.
Item
R/W
Description
0000 hex
−
Not used
−
Not accessible
0001 hex
0000 hex
RUN command
R/W
1: Run
0: Stop (Enabled when A002/A202 =
03)
0002 hex
0001 hex
Rotation direction command
R/W
1: Reverse
0: Forward (Enabled when A002/A202
= 03)
0003 hex
0002 hex
External Trip (EXT)
R/W
1: Trip
0004 hex
0003 hex
Trip reset (RS)
R/W
1: Reset
0005 hex
−
Reserved
−
−
0006 hex
0007 hex
0006 hex
Multi-function Input 1
*1
R/W
1: ON
0: OFF
0008 hex
0007 hex
Multi-function Input 2
*1
R/W
1: ON
0: OFF
0009 hex
0008 hex
Multi-function Input 3
*1
R/W
1: ON
0: OFF
000A hex
0009 hex
Multi-function Input 4
*1
R/W
1: ON
0: OFF
000B hex
000A hex
Multi-function Input 5
*1
R/W
1: ON
0: OFF
000C hex
000B hex
Multi-function Input 6
*1
R/W
1: ON
0: OFF
000D hex
000C hex
Multi-function Input 7
*1
R/W
1: ON
0: OFF
000E hex
−
Reserved
−
−
000F hex
000E hex
Operation status
R
1: Run
0: Stop (Interlocked with d003)
*1. These input terminals can be turned ON/OFF via Modbus communication. This inverter recognizes that an in-
put terminal is ON when it is turned ON either via communications or by the input signal to the control circuit
terminal block.
8
8-9 Modbus Communication Data Lists
8-9-1 Coil Number List

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
