7 Other Functions
7 - 9
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
7-1-13 Input Power Monitor [d014]
7-1-13 Input Power Monitor [d014]
Use this function to display the input power (instantaneous value) of the inverter.
Parameter
No.
Function name
Data
Default
data
Unit
d014
Input Power Monitor
0.0 to 100.0
−
kW
7-1-14 Integrated Power Monitor [d015]
Use this function to display the integrated power of the inverter.
The monitor value can be converted and displayed with a different scale factor by setting the Integrated
Power Display Scale (b079).
d015 = Actual integrated power / Integrated Power Display Scale (b079)
(Example) If the monitor value is 1000 when b079 is set to 100, the actual integral power is
100,000 [kWh].
To clear the integrated power value, set the Integrated Power Clear (b078) to 01.
It is also possible to clear the integrated power value via terminal input by setting one of the Multi-func-
tion Input 1 to 7 Selection (C001 to C007) to 53 (KHC: Integrated power clear).
If the Integrated Power Display Scale (b079) is set to 1000, an integrate power value of up to
1,000,000,000 [kWh] can be displayed.
This parameter value will be stored to the inverter’s EEPROM when the power supply is shut off.
*1. The digit shift display mode can be used.
Parameter
No.
Function name
Data
Default
data
Unit
d015
Integrated Power Monitor
0.0 to 1000000.0
*1
−
−
b078
Integrated Power Clear
00: Clear disabled
01: Clear with the Enter key
(Data is reset from 01 to 00 after exe-
cution.)
00
−
b079
Integrated Power Display
Scale
1. to 1000.
1.
−
C001 to
C007
Multi-function Input S1 to
7 Selection
53: KHC (Integrated power clear)
−
−
7
7-1 Monitor Mode
