Omron MX2 Series User Manual

4 Parameter List
4 - 35
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
4-3-5 Group P: Option/Applied Function Parameters
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Auxiliary
function
P001
Operation Selection on
Option Error
00: Trip
01: Continue operation
00
Enabled
−
P. 7-105
P003
Pulse Train Input EA
Selection
00: Frequency setting (including PID)
01: Feedback pulse (enabled only
when 1st control is selected)
02: MI8 (General-purpose input 8 for
DriveProgramming)
00
Disabled
−
P. 6-18
P. 7-52
Simple
position
control
P004
Pulse Train Input Type
Selection
00: Single-phase pulse train
01: Phase A and B 90°phase difference
pulse train
02: Do not set.
03: Single-phase pulse train + direction
00
Disabled
−
P. 6-18
P. 6-28
P011
Number of Encoder
Pulses
32. to 1024.
512.
Disabled
pulse
P012
Simple Position Con-
trol Selection
00: Simple position control disabled
02: Simple position control enabled
00
Disabled
−
P. 6-34
P. 6-50
P014
Creep Speed Moving
Amount
0.0 to 400.0
125.0
Disabled
%
P015
Creep Speed Setting
Starting Frequency to 10.00 (100.00)
*1
5.00
Enabled
Hz
P017
Positioning Completion
Range Setting
*1
0. to 10000. (×4 multiplication)
50.
Disabled
pulse
P. 6-45
P026
Overspeed Error
Detection Level
0.0 to 150.0
115.0
Enabled
%
P. 6-23
P027
Speed Deviation
Excessive Level
0.00 to 120.00
10.00
Enabled
Hz
Auxiliary
function
P031
Acceleration/Decel-
eration Time Input
Type
00: Digital Operator
03: DriveProgramming
00
Disabled
−
P. 5-32
Torque
control
P033
Torque Reference
Input Selection
00: Terminal O
01: Terminal OI
03: Digital Operator
06: Option (No applicable Option)
00
Disabled
−
P. 6-16
P034
Torque Reference
Setting
0. to 200.
0.
Enabled
%
P036
Torque Bias Selection
00: Disabled
01: Digital Operator
05: Option (No applicable Option)
00
Disabled
−
P. 6-17
P037
Torque Bias Value
−200. to 200.
0.
Enabled
%
P038
Torque Bias Polarity
Selection
00: As per sign
01: Dependent on RUN direction
00
Disabled
−
P039
Speed Limit Value in
Torque Control (For-
ward)
0.00 to 120.00
0.00
Enabled
Hz
P. 6-16
P040
Speed Limit Value in
Torque Control
(Reverse)
0.00 to 120.00
0.00
Enabled
Hz
P041
Speed/Torque
Switching Time
0. to 1000.
0.
Disabled
ms
*1. In high-frequency mode.
4
4-3 Extended Function Mode
4-3-5 Group P: Option/Applied Function Parameters

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
