7-1-32 Regenerative Braking Load Rate Monitor [d103]
Use this function to display the regenerative braking load rate. If this monitor value exceeds the value
set in the Usage Rate of Regenerative Braking (b090), the inverter will trip with the alarm code E06
(Braking resistor overload protection).
Parameter
No.
Function name
Data
Default
data
Unit
d103
Regenerative Braking
Load Rate Monitor
0.0 to 100.0
−
%
Related functions
b090
7-1-33 Electronic Thermal Load Rate Monitor [d104]
Use this function to display the electronic thermal load rate. If this monitor value exceeds 100%, the
inverter will trip with the alarm code E05 (Overload protection).
If the Electronic Thermal Load Rate Memory Selection at Power-off (b914) is set to 01 (Enabled), the
value will be stored in EEPROM when the power supply is turned OFF.
Parameter
No.
Function name
Data
Default
data
Unit
d104
Electronic Thermal Load Rate
Monitor
0.0 to 100.0
−
%
Related functions
b914
7-1-34 Analog Voltage Input O Monitor [d130]
Use this function to monitor the state of the analog voltage that is input to the analog voltage reference
terminal O for frequency reference input.
It displays the maximum input value for the terminal O (equivalent to 10.9 V) as 1023 bits.
Parameter
No.
Function name
Data
Default
data
Unit
d130
Analog Voltage Input O Monitor
0 to 1023
−
−
7-1-35 Analog Current Input OI Monitor [d131]
Use this function to monitor the state of the analog current that is input to the analog current reference
terminal OI for frequency reference input.
It displays the maximum input value for the terminal OI (equivalent to 23.3 mA) as 1023 bits.
Parameter
No.
Function name
Data
Default
data
Unit
d131
Analog Current Input OI Monitor
0 to 1023
−
−
