1 Overview
1 - 6
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
1-1-2 Classes of 3G3MX2-EV2 Series Inverter
There are three voltage classes for 3G3MX2-EV2 Series Inverters: Single-phase 200 VAC, 3-phase 200
VAC and 3-phase 400 VAC.
The maximum applicable motor capacity for this Inverter is 0.1 to 15 kW for the heavy load mode and
0.2 to 18.5 kW for the light load mode.
All models comply as standard with the EC Directives and UL/cUL Standards.
Rated voltage
Enclosure
rating
Maximum applicable motor capacity
Model
CT: Heavy load
VT: Light load
3-phase 200 VAC
IP20
0.1 kW
0.2 kW
3G3MX2-A2001-EV2
0.2 kW
0.4 kW
3G3MX2-A2002-EV2
0.4 kW
0.75 kW
3G3MX2-A2004-EV2
0.75 kW
1.1 kW
3G3MX2-A2007-EV2
1.5 kW
2.2 kW
3G3MX2-A2015-EV2
2.2 kW
3.0 kW
3G3MX2-A2022-EV2
3.7 kW
5.5 kW
3G3MX2-A2037-EV2
5.5 kW
7.5 kW
3G3MX2-A2055-EV2
7.5 kW
11 kW
3G3MX2-A2075-EV2
11 kW
15 kW
3G3MX2-A2110-EV2
15 kW
18.5 kW
3G3MX2-A2150-EV2
3-phase 400 VAC
IP20
0.4 kW
0.75 kW
3G3MX2-A4004-EV2
0.75 kW
1.5 kW
3G3MX2-A4007-EV2
1.5 kW
2.2 kW
3G3MX2-A4015-EV2
2.2 kW
3.0 kW
3G3MX2-A4022-EV2
3.0 kW
4.0 kW
3G3MX2-A4030-EV2
4.0 kW
5.5 kW
3G3MX2-A4040-EV2
5.5 kW
7.5 kW
3G3MX2-A4055-EV2
7.5 kW
11 kW
3G3MX2-A4075-EV2
11 kW
15 kW
3G3MX2-A4110-EV2
15 kW
18.5 kW
3G3MX2-A4150-EV2
Single-phase 200 VAC
IP20
0.1 kW
0.2 kW
3G3MX2-AB001-EV2
0.2 kW
0.4 kW
3G3MX2-AB002-EV2
0.4 kW
0.55 kW
3G3MX2-AB004-EV2
0.75 kW
1.1 kW
3G3MX2-AB007-EV2
1.5 kW
2.2 kW
3G3MX2-AB015-EV2
2.2 kW
3.0 kW
3G3MX2-AB022-EV2
