8-9-3 Group F Register List
Precautions for Correct Use
• The “Register No.” in the table header shows the register number used inside the inverter.
Use this register number when setting EtherCAT communications.
• The “Modbus register spec. No.” in the table header shows the register number used to actu-
ally specify the register in the Modbus communication process.
This register number is 1 less than the inverter “Register No.” according to the Modbus com-
munication specifications.
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
1103 hex
1102 hex
1st Acceleration
Time 1
F002
(HIGH)
R/W
0 to 360000
0.01 [s]
P. 5-32
1104 hex
1103 hex
F002
(LOW)
1105 hex
1104 hex
1st Deceleration
Time 1
F003
(HIGH)
R/W
0 to 360000
0.01 [s]
1106 hex
1105 hex
F003
(LOW)
1107 hex
1106 hex
RUN Direction
Selection
F004
R/W
00: Forward
01: Reverse
−
P. 5-21
1108 to
1200 hex
−
Not used
−
−
Not accessible
−
−

Omron MX2 Series Specifications

General

Cooling Method	Fan cooling
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, overvoltage, undervoltage, overload, overheating, short circuit
Communication Options	Modbus RTU
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Ambient Operating Temperature	-10°C to +50°C
Enclosure	IP20
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Power Supply Voltage	200-240V AC
Input Voltage	3-phase 200-240V AC
