Omron MX2 Series - 2 Nd Control Selection Signal (SETM); Ground Fault Detection Selection

7 Other Functions
7 - 93
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
7-8-23 2nd Control Selection Signal (SETM)
This signal will be output when the SETM (Motor 2 selection) function is allocated to one of the
multi-function output terminals and the terminal SET is ON.
Parameter
No.
Function name
Data
Default
data
Unit
C021, C022
Multi-function Output 11/12 Selection
60: SETM (Motor 2 selec-
tion)
−
−
C026
Multi-function Relay Output (AL1, AL2)
Function Selection
7-8-24 Ground Fault Detection Selection
Select whether to enable or disable ground fault detection between the inverter output and the motor at
power-on.
If a ground fault is detected, a ground-fault trip Ground protection (E14.) occurs to protect the inverter.
Parameter
No.
Function name
Data
Default
data
Unit
b098
Ground Fault Detection Selection
00: Disabled
01:
Enabled
01
−
