8 Communications Functions
8 - 60
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
12BD hex
12BC hex
Deceleration Stop
Frequency
A154
(HIGH)
R/W
0 to Starting Frequency:
Disabled
Frequency above Starting
Frequency to 59000
0.01
[Hz]
P. 7-37
12BE hex
12BD hex
A154
(LOW)
12BF hex
12BE hex
Deceleration Stop
Time
A155
R/W
0: Disabled
1 to 600
0.1 [s]
12C0 hex
12BF hex
PID Sleep Operation
Level
A156
(HIGH)
R/W
0 to 59000
0.01
[Hz]
P. 7-44
12C1 hex
12C0 hex
A156
(LOW)
12C2 hex
12C1 hex
PID Sleep Operation
Delay Time
A157
R/W
0 to 255
0.1 [s]
12C3 to
12C5 hex
−
Reserved
−
−
−
−
−
12C6 hex
12C5 hex
VR Start Frequency
A161
(HIGH)
R/W
0 to 59000
0.01
[Hz]
P. 7-25
12C7 hex
12C6 hex
A161
(LOW)
R/W
12C8 hex
12C7 hex
VR End Frequency
A162
(HIGH)
R/W
0 to 59000
0.01
[Hz]
12C9 hex
12C8 hex
A162
(LOW)
R/W
12CA hex
12C9 hex
VR Start Ratio
A163
R/W
0 to VR End Ratio
1 [%]
12CB hex
12CA hex
VR End Ratio
A164
R/W
VR Start Ratio to 100
1 [%]
12CC
hex
12CB hex
VR Start Selection
A165
R/W
00: VR Start Fre-
quency (A161)
01: 0 Hz
−
12CD to
1300 hex
−
Not used
−
−
Not accessible
−
−
1301 hex
1300 hex
Power Interruption/
Undervoltage
Restart Selection
b001
R/W
00: Trip
01: 0-Hz restart
02: Frequency pull-in
restart at shutoff
03: Trip after frequency
pull-in decelera-
tion stop
04: Frequency pull-in
restart
−
P. 7-62
1302 hex
1301 hex
Allowable Power
Interruption Time
b002
R/W
3 to 250
0.1 [s]
1303 hex
1302 hex
Restart Standby
Time
b003
R/W
3 to 1000
0.1 [s]
P. 7-62
1304 hex
1303 hex
Power Interruption/
Undervoltage Trip
Selection During
Stop
b004
R/W
00: Disabled
01: Enabled
02: Disabled during stop
and deceleration stop
by turning off the
RUN command
−
P. 7-64
1305 hex
1304 hex
Power Interruption
Restart Count
b005
R/W
00: 16 times
01: No limit
−
1306 hex
−
Reserved
−
−
−
−
−
