8 Communications Functions
8 - 70
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Register
No.
Modbus
register
spec. No
Function name
Parameter
No.
R/W
Monitor or setting data
Data
resolution
Page
13A9 hex
−
(Reserved)
b166
−
Do not change the
default 00.
−
−
13AA to
13AD hex
−
Reserved
−
−
−
−
−
13AE hex
13AD hex
Inverter Mode
Selection
b171
R/W
00: Selection disabled
01: Induction motor
mode
02: Induction motor
high-frequency
mode
03: PM motor mode
−
P. 6-58
13AF to
13B6 hex
−
Reserved
−
−
−
−
−
13B7 hex
13B6 hex
Initialization
Execution
b180
R/W
00: Function disabled
01: Execute initializa-
tion
−
P. 5-5
13B8 to
13C5 hex
−
Not used
−
−
Not accessible
−
−
13C6 hex
13C5 hex
Motor Electronic
Thermal Selection
b910
R/W
00: Disabled
01: Enabled (fixed sub-
traction ratio)
02: Enabled (b911
subtraction ratio)
03: Enabled (b912
time parameter
subtraction)
−
P. 7-74
13C7 hex
13C6 hex
Motor Electronic
Thermal Subtraction
Ratio
b911
(HIGH)
R/W
10 to 10000000
0.01
[s]
P. 7-74
13C8 hex
13C7 hex
b911
(LOW)
13C9 hex
13C8 hex
Motor Electronic
Thermal Subtraction
Time Constant
b912
(HIGH)
R/W
10 to 10000000
0.01
[s]
P. 7-74
13CA hex
13C9 hex
b912
(LOW)
13CB hex
13CA hex
Motor Electronic
Thermal Integration
Gain
b913
R/W
10 to 2000
0.1 [%]
P. 7-74
13CC hex
13CB hex
Electronic Thermal
Load Rate Memory
Selection at
Power-off
b914
R/W
00: Disabled
01: Enabled
−
P. 7-74
13CD to
1400 hex
−
Not used
−
−
Not accessible
−
−
• For Modbus communication, the parameters b150, b160, and b161 have no corresponding registers.
