11 Maintenance and Inspection
12 - 13
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Motor
Diode
600 V 0.1 A min. (200-V class)
1000 V 0.1 A min. (400-V class)
2 W 220 kW
+
VDC
VAC = 1.1  VDC
Moving coil type
−
300 V (200-V class)
600 V (400-V class)
W
T
Inverter
S V
11
11-1 Maintenance and Inspection
11-1-8 I/O Voltage/Current/Electric
Power Measurement Method
