Page #294 background image
How to Use Data Trace Recording Tool Appendix
258
10. Set options. The following settings are available.
• Add saving Add data to the existing file.
• Multiple Saving Divide and save the data to multiple files when the
number of sampling data exceeds the limit of the
Data Trace file (.cdt).
11. Click the [OK] button when setting options completes to return to the ex-
ecution window.
12. When tracing with the same settings, click the [Add Recording] button to
save the settings to the file (.ini).
13. Click the [Start] button when setting completes to register the setting
contents to the target PLC and to start tracing.
14. While tracing, the elapsed time after the execution started, the number of
tracing samples, and the name of actually saved files (including serial
numbers for multiple saving) will be displayed.
15. Holding of the abort value will automatically stop tracing. Click the [Stop]
button to forcibly stop tracing during execution.
Stating from the Command Line
The [Data Trace Recording Tool] can be started from the command line of the
MS-DOS command prompt, etc. with the setting file (.ini) specified that has
been saved by the [Add Recording] button, as well as from [Start] | [Execute by
Specifying File Name]. If a setting file is specified when starting, the [Data
Trace Recording Tool] will automatically start the data trace.
Follow the next procedure to start from the command line.
Data Record [< Name of setting file >]
Data Record Execution command
< Name of setting file > <Options>
Specify a setting file for saving the traced
data automatically.
If a setting file is specified, tracing will be
started according to the settings.
If not or a non-existing file is specified, the
data trace will not start.
