Itala | INSTRUCTION MANUAL
Feature Description Interface Access
UserSetSelector Selects the feature User Set to
load, save or configure
IInteger RW
UserSetLoad Loads the User Set specified by
UserSetSelector to the device
and makes it active
ICommand RW
UserSetSave Save the User Set specified by
UserSetSelector to the
non-volatile memory of the
device
ICommand RW
UserSetDefault Selects the feature User Set to
load and make active by default
when the device is reset
IEnumeration RW
Table 32: User Set Control Features
6.15 Chunk Data Control
This section describes all the features related to the chunk data.
Feature Description Interface Access
ChunkModeActive Activates the inclusion of Chunk
data in the payload of the image
IBoolean RW
ChunkSelector Selects which Chunk to enable or
control
IEnumeration RW
ChunkEnable Enables the inclusion of the
selected Chunk data in the
payload of the image
IBoolean RW
ChunkWidth Returns the Width of the image
included in the payload
IInteger R
ChunkHeight Returns the Height of the image
included in the payload
IInteger R
ChunkOffsetX Returns the OffsetX of the image
included in the payload
IInteger R
ChunkOffsetY Returns the OffsetY of the image
included in the payload
IInteger R
ChunkPixelFormat Returns the PixelFormat of the
image included in the payload
IEnumeration R
ChunkExposureTime Returns the exposure time used
to capture the image
IFloat R
v1.12 - eng 99
