ChunkGain Returns the gain used to capture
the image
IFloat R
ChunkBlackLevel Returns the black level used to
capture the image included in
the payload
IFloat R
ChunkTimestamp Returns the Timestamp of the
image included in the payload at
the time of the FrameStart
internal event
IInteger R
ChunkFrameID Returns the unique Identifier of
the frame (or image) included in
the payload
IInteger R
ChunkSequencerSetActive Returns the index of the active
set of the running sequencer
included in the payload
IInteger R
Table 33: Chunk mode Control Features
6.16 OE Serial Interface Control
This section deals with the serial communication features.
Feature Description Interface Access
oeSerialEnable Enable the serial interface IBoolean RW
oeSerialBaudRate Select the serial interface baud
rate
IEnumeration RW
oeSerialMode Select the serial interface mode
of operation
IEnumeration RW
oeSerialProtocol Select the protocol to use on the
serial interface
IEnumeration RW
oeSerialSlewRate Select the slew rate of the serial
interface data
IEnumeration RW
oeSerialASCIIWriteBuffer Character write buffer of the
serial interface
IString RW
oeSerialASCIIWrite Start a write operation on the
serial interface
ICommand RW
oeSerialASCIIReadCount Number of bytes to read from
serial input buffer
IInteger RW
oeSerialASCIIReadBuffer Character read buffer of the
serial interface
IString R
