Itala | INSTRUCTION MANUAL

6.8 Digital I/O Control

The Digital I/O chapter covers the features required to control the general Input and Output signals

of the device. These include input and output control signals for triggering timers, counters and

also static signals such as user conﬁgurable input or output bits.

Feature Description Interface Access

LineSelector Selects the physical line (or pin)

of the external device connector

or the virtual line of the

Transport Layer to conﬁgure

IEnumeration RW

LineMode Controls if the physical Line is

used to Input or Output a signal

IEnumeration RW

LineInverter Controls the inversion of the

signal of the selected input or

output Line

IBoolean RW

LineStatus Returns the current status of the

selected input or output Line

IBoolean R

LineStatusAll Returns the current status of all

available Line signals at time of

polling in a single bit ﬁeld

IInteger R

LineSource Selects which internal acquisition

or I/O source signal to output on

the selected Line

IEnumeration RW

oeDebounceEnable Enable the input debounce

circuitry. This allows to ﬁlter the

input signal and ignore spurious

commutations.

IBoolean RW

oeDebounceAmount Amount of time for which the

input signal need to stay

constant in order to be

recognized as a valid input

IFloat RW

oePulseGeneratorEnable Override the output signal with a

pulse generated at the rising

edge of the signal speciﬁed by

LineSource

IBoolean RW

oePulseGeneratorPeriod Sets the duration of the output

signal pulse

IFloat RW

UserOutputSelector Selects which bit of the User

Output register will be set by

UserOutputValue

IEnumeration RW

v1.12 - eng 86
