• a fixed blue gradient pattern, from black to blue;
• a fixed color bars pattern (all the possible combinations of R, G and B coordinates).
6.3 Acquisition Control
The Acquisition Control section describes all features related to image acquisition, including the
trigger and exposure control. It describes the basic model for acquisition and the typical behavior
of the device.
Feature Description Interface Access
AcquisitionMode Sets the acquisition mode of
the device. It defines mainly
the number of frames to
capture during an acquisition
and the way the acquisition
stops
IEnumeration RW
AcquisitionStart Starts the Acquisition of the
device
ICommand RW
AcquisitionStop Stops the Acquisition of the
device at the end of the current
Frame
ICommand RW
AcquisitionBurstFrameCount Number of frames to acquire
for each FrameBurstStart
trigger
IInteger RW
AcquisitionFrameRate Controls the acquisition rate (in
Hertz) at which the frames are
captured
IFloat RW
AcquisitionFrameRateEnable Controls if the
AcquisitionFrameRate feature
is writable and used to control
the acquisition rate. Otherwise,
the acquisition rate is implicitly
controlled by the combination
of other features like
ExposureTime, etc..
IBoolean RW
oeAcquisitionFrameRateLimitMode Select what limits the
acquisition frame rate
IEnumeration RW
oeResultingFrameRate Shows the resulting acquisition
frame rate
IFloat RO
TriggerSelector Selects the type of trigger to
configure
IEnumeration RW
