Itala | INSTRUCTION MANUAL
GevSCDA Controls the destination IP
address of the selected stream
channel to which a GVSP
transmitter must send data
stream or the destination IP
address from which a GVSP
receiver may receive data stream
IInteger RW
GevSCSP Indicates the source port of the
stream channel
IInteger R
Table 38: Transport Layer Control Features
6.20.1 Precision Time Protocol (PTP)
PTP (Precision Time Protocol) is a clock synchronization protocol of IEEE 1588 standard. It allows
to precisely synchronize clocks of multiple GigE cameras on an ethernet network. PTP procedure
establishes that the device with the most accurate clock in the network is elected as grandmaster
clock and other devices becomes slaves. Slaves periodically and automatically synchronize their
clock directly with the master’s clock. The result is that the timestamp values are aligned with the
master over the entire network. This protocol is closely described in the IEEE standard document.
NOTE: Itala cameras can become only slave (master mode is not implemented).
The PTP feature must be enabled if the scheduled action commands are used (6.12.2).
6.21 Sequencer Control
This section describes all the features related to the Sequencer Control.
Feature Description Interface Access
SequencerMode Controls if the sequencer
mechanism is active
IEnumeration RW
SequencerConfigurationMode Controls if the sequencer
configuration mode is active
IEnumeration RW
SequencerFeatureSelector Selects which sequencer
features to control
IEnumeration RW
SequencerFeatureEnable Enables the selected feature and
make it active in all the
sequencer
IBoolean RW
v1.12 - eng 109
