Oracle SPARC S7-2 Service Manual

Device Paths
Device NAC Name Description Device Path PCIe
Switch
Physical
Port
Device
Number
Owned By Width
/SYS/MB/USB_CTLR
USB host
controller
/pci@300/pci@1/pci@0/
pci@2/usb@0
SW 0 Port 12 pci@2 CPU 0 x1
/SYS/MB/XGBE
Ethernet
controller
/pci@300/pci@1/pci@0/
pci@1
SW 0 Port 4 pci@1 CPU 0 x8
/SYS/MB/NET0
NET 0
interface
/pci@300/pci@1/pci@0/
pci@1/network@0
SW 0 Port 4 pci@1 CPU 0 x8
/SYS/MB/NET1
NET 1
interface
/pci@300/pci@1/pci@0/
pci@1/network@0,1
SW 0 Port 4 pci@1 CPU 0 x8
/SYS/MB/NET2
NET 2
interface
/pci@300/pci@1/pci@0/
pci@1/network@0,2
SW 0 Port 4 pci@1 CPU 0 x8
/SYS/MB/NET3
NET 3
interface
/pci@300/pci@1/pci@0/
pci@1/network@0,3
SW 0 Port 4 pci@1 CPU 0 x8
/SYS/MB/RISER1/PCIE1
PCIe slot 1
/pci@302/pci@1/pci@0/
pci@11
SW 0 Port 8 pci@11 CPU 1 x8
(physical
x16)
/SYS/MB/RISER2/PCIE2
PCIe slot 2
/pci@302/pci@1/pci@0/
pci@12
SW 0 Port 6 pci@12 CPU 1 x8
(physical
x16)
/SYS/MB/RISER3/PCIE3
PCIe slot 3
/pci@300/pci@2/pci@0/
pci@13
SW 1 Port 12 pci@13 CPU 0 x8
/SYS/MB/RISER3/PCIE4
PCIe slot 4
/pci@302/pci@2/pci@0/
pci@14
SW 1 Port 8 pci@14 CPU 1 x8
/SYS/DBP/NVME0
NVMe
drive in
HDD slot 2
/pci@300/pci@2/pci@0/
pci@4/nvme@0/disk@1
SW 1 Port 4 pci@4 CPU 0 x4
/SYS/DBP/NVME1
NVMe
drive in
HDD slot 3
/pci@300/pci@2/pci@0/
pci@5/nvme@0/disk@1
SW 1 Port 5 pci@5 CPU 0 x4
/SYS/DBP/NVME2
NVMe
drive in
HDD slot 4
/pci@302/pci@2/pci@0/
pci@6/nvme@0/disk@1
SW 1 Port 6 pci@6 CPU 1 x4
/SYS/DBP/NVME3
NVMe
drive in
HDD slot 5
/pci@302/pci@2/pci@0/
pci@7/nvme@0/disk@1
SW 1 Port 7 pci@7 CPU 1 x4
/SYS/DBP/HDD0
SAS/SATA
drive in
slot 0
/pci@302/pci@2/pci@0/
pci@14/LSI,sas@0/
disk@p2
SW 1 Port 8 pci@14 CPU 1
/SYS/DBP/HDD1
SAS/SATA
drive in
slot 1
/pci@302/pci@2/pci@0/
pci@14/LSI,sas@0/
disk@p3
SW 1 Port 8 pci@14 CPU 1
/SYS/DBP/HDD2
SAS/SATA
drive in
slot 2
/pci@302/pci@2/pci@0/
pci@14/LSI,sas@0/
disk@p1
SW 1 Port 8 pci@14 CPU 1
Identifying Components 17
