Servicing the Front Indicator Module
The FIM is mounted on left side of the chassis face next to the drives. See “Front Panel
Components” on page 11.
■
“Remove the FIM” on page 111
■
“Install the FIM” on page 113
Related Information
■
“Detecting and Managing Faults” on page 21
■
“Preparing for Service” on page 33
Remove the FIM
This is a cold-service procedure that must be performed by qualified service personnel. Power
down the server completely before performing this procedure.
1.
Prepare for servicing.
See “Preparing for Service” on page 33.
Servicing the Front Indicator Module 111
