Remove a Power Supply
For instructions for disconnecting the CMA left-side connectors, see “Remove the Cable
Management Arm” on page 42.
Caution - When disconnecting the CMA left-side connectors, use your arm to support the
CMA so that it does not hang down under its own weight and stress the right-side connectors;
otherwise, the CMA might be damaged. You must continue to support the CMA until you have
reconnected both of the left-side connectors.
4.
Disconnect the power cord from the faulty power supply.
5.
Grasp the power supply handle and push the power supply latch to the left (1).
No. Description
1 Power supply 0
2 Power supply 1
6.
Pull the power supply out of the chassis (2).
7.
Replace the power supply immediately.
See “Install a Power Supply” on page 72.
Caution - Replace the power supply within 5 minutes to ensure proper system cooling.
Servicing Power Supplies 71
