26 | Ottobock Helix
Explanation of symbols
English
WARNING
Warnings regarding possible risks of severe accident or injury.
CAUTION
Warnings regarding possible risks of accident or injury.
NOTICE
Warnings regarding possible technical damage.
INFORMATION
Additional information on the tting / use.
Recommended accessories and materials for orthopaedic technicians:
743L100 L.A.S.A.R. Posture (647H189 Instructions for Use)
743L200/743L300 L.A.S.A.R. Assembly (647H193 Instructions for Use) or
743A200 PROS.A. Assembly (647H534 Instructions for Use)
743G5 Hip-Cast Casting Apparatus
743A29 Reference Determination Tool
616T52=1225 ×1225 × 6 ThermoLyn, rigid, for HD check sockets
616T52=1225 ×1225 × 8 ThermoLyn, rigid, for HD check sockets
1 Important information about the Helix
3D
Hip Joint System
INFORMATION
Before using the Helix
3D
Hip Joint System, please read these Instructions for Use carefully and pay special at-
tention to the safety information!
The prosthesis wearer must be taught how to handle, care for and operate his/her prosthesis properly. Please
see the following Sections:
1.3 Conditions of Use,
1.5 Safety Instructions,
5.1 Technical Information
5.3 Legal information
1.1 Medical purpose
The Helix
3D
Hip Joint System is to be used exclusively for the exoprosthetic tting of patients with hip amputations
such as intertrochanteric amputation, hip disarticulation or hemipelvectomy.
1.2 Field of application
The Helix
3D
Hip Joint can be used by active prosthesis wearers as well as by prosthesis wearers who require a
high degree of safety. Thanks to its hydraulic stance phase and swing phase control it offers functional safety
and dynamic comfort.
Field of application according to the Ottobock MOBIS® Mobility System:
Recommended for mobility grades 2 and 3 (restricted outdoor walker,
unrestricted outdoor walker).
Approved for a body weight of up to 100 kg/220 lbs.
