910-257C March 2006
Page 1-2 MG2 Series
play under all lighting conditions, selectable calibration lockout
functions to prevent accidental change to calibration, selectable
resolutions .001" (.01mm) or .01" (.1mm), and easy calibration
for unknown material velocity and/or transducer zero.
• MG2-DL - Features include: Quick compensations for transducer
temperature changes, fast scan min hold mode with 20 readings/
sec and freeze function, freeze function that instantly freezes dis-
played measurement, differential mode that displays the differ-
ence between the actual thickness and a user set nominal
reference value, THRU-COAT
®
that displays the thickness of the
coating and the true metal thickness using a single backwall
echo, Echo-to-Echo that displays the true metal thickness and
ignores the thickness of the coating layer, High-Low Alarm that
indicates out of tolerance measurements, Gain Adjustment to
help enable measurements in difficult applications, Material Sen-
sitivity Optimization, On-Board Datalogger for storage of up to
8000 thickness readings, and USB output for computer interface.
Table 1 below lists MG2 Series features:
Table 1: MG2 Series Features
MG2 Series Features
MG2 MG2-XT MG2-DL
Thickness Range 0.020"-25.00"
(0.50-635.0 mm)
•••
Compatible with Complete Line of
Dual Element Transducers
•••
Thickness Display Resolution up
to 0.001" (0.01 mm)
•••
