measurement location path. The ID sequence created in the
computer must have setup information.
Data downloaded to the MG2-DL gage must be in the same format in
which data is transmitted. Panametrics-NDT
TM
recommends using the
GageView Interface Program to manage all functions of interfacing,
storing, and creating MG2-DL data.
5.9.2 Using the Optional GageView Interface
Program
GageView is the interface program for the MG2-DL. GageView is a
Windows
®
-based program compatible with Windows 2000
®
and XP
®
.
It can create inspection database files, load data files, and generate
reports. GageView is compatible with MG2-DL data files and offers
advanced ODBC compatibility and enhanced OLE features.
For more information on GageView, refer to the GageView
Instruction Manual.
5.10 Statistics Reports
The MG2-DL can generate statistic reports from within the gage without
having to connect to a computer.
5.10.1 Statistics Report for an Entire File
Step 1: Press [2
nd
F][ ](FILE) to go to the File tabs.
Step 2: Press [ ] to scroll to Stats tab.
Step 3: Press [ ] to enter the Stats tab.
