910-257C March 2006
Page 4-24 MG2 Series
and MG2-DL Series unit.
Activate the Live Waveform software through the following
procedure:
Step 1: Press [2
nd
F], [ ] (SETUP).
Step 2: Use the [ ] key to select the License tab.
Step 3: Press [ENTER] twice. The gage displays a license name.
Step 4: Enter the License Code provided by Panametrics-NDT using
the [ ,
, , ] keys and then press [ENTER].
Step 5: Use the [ , ] keys to select Done and press [ENTER].
Step 6: Press [ENTER] to accept.
Step 7: Power the unit Off, then On again to complete the Live
Waveform activation.
4.12 Optional Waveform (MG2-XT and
MG2-DL Only)
The Live Waveform option for MG2-XT and MG2-DL Series gages
allows the user to view the live ultrasonic waveform to help align the
transducer for difficult applications. When this feature is added, the
user can change between the standard thickness display and the
optional live waveform display.
Other Waveform setup features include:
• Zoom Option: This mode automatically adjusts the ranges and
delay so the measured echoes will always be displayed on the
waveform.
