March 2006 910-257C
MG2 Series Page 4-23
features to the MG2-XT and MG2-DL gages and enhances overall
performance for difficult measurement applications.
The following advanced capabilities are available when the Live
Waveform feature is added:
• Manual Gain adjustment in 1 dB increments
• Extended Blank (Material Sound Entry Blank)
• Manual Echo-to-Echo
• E1 Blank (for Manual Echo-to-Echo only)
• Range
• Delay
Note: These features are available only when the Waveform
Mode is activated and are not available when the gage is
operating in standard Thickness Mode.
If the Live Waveform Option has been purchased, then the optional
software will already have been loaded and activated. When this
feature is activated, a Waveform tab appears in the Setup menu.
If the Live Waveform software was purchased after the unit was
initially supplied, then the Waveform Option must be activated using a
unique license name and license name code system.
Each MG2-XT and MG2-DL Series gage generates a unique license
name. To activate the internal Live Waveform feature, the user must
enter a valid license code. Contact Panametrics-NDT
TM
or our local
Panametrics-NDT representative to obtain a valid license code for the
license name. This license code is not valid for any other MG2-XT
