Panametrics MG2 - Diff Mode (MG2-XT and MG2-DL Only)

March 2006 910-257C
MG2 Series Page 4-17
Note: The Alarm Mode and the Diff Mode are mutually exclu-
sive (cannot be used at the same time). If one of these
functions is activated, it will be automatically turned off
when the other function is turned on.
To activate the High/Low Alarm:
Step 1: Press [2ndF][ ](Setup) to display the setup tabs.
Step 2: Use the [ , ] keys to highlight the Alarm tab.
Step 3: Use the [ ] key to highlight Enable and [ , ] to select
On or Off.
Step 4: Press the [ ] key to highlight Lo-Alarm and then press
[ ] key and use the [ , ,
, and ] keys to edit the
low alarm set point.
Step 5: Press the [ENTER] key to highlight Hi-Alarm, then press
[] and the [ ,
, , and ] keys to slew to the high
alarm set point.
Step 6: Press [MEAS] to return to the Measure Mode.
4.8 Diff Mode (MG2-XT and MG2-DL
Only)
Diff Mode allows the user to set a differential set point. When Diff
Mode is activated, the gage displays the difference between the Diff
set point and the actual thickness value. The gage displays a “D” to
indicate that Diff Mode is active.
