March 2006 910-257C
MG2 Series Page 4-35
Step 3: Press [ , ] to adjust the range.
Step 4: Press [MEAS] to exit the Waveform Adjust Mode with the
Range set at the adjusted values.
4.13.5 Delay
Delay Adjust allows the user to adjust the waveform delay so that the
measured echoes appear on screen. Delay Adjust is not available if the
waveform Zoom Options is turned on.
To adjusting the range when in Live Waveform Mode, press the [ ,
] keys to increase or decrease the Waveform Delay.
To adjust the delay in Waveform Adjust Mode:
Step 1: Press [2
nd
F],[ ] (Gain).
Step 2: Press [ ] or [ ] to select the Delay Setup parameter.
Step 3: Press [ , ] to adjust the Delay.
Step 4: Press [MEAS] to exit Waveform Adjust Mode with the Delay
set at adjusted values.
