910-257C March 2006
Page 4-16 MG2 Series
4.6.5 36DLP Output (MG2-DL Only)
36DLP Output allows the user to choose to output the thickness data
in a special 36DL PLUS output format. This will allow the MG2-DL
to communicate with software programs that communicates with the
36DL PLUS. The MG2-DL will mimic the output format of the 36DL
PLUS when the 36DLP Output is set to On.
To Activate 36DLP Output:
Step 1: Press [2ndF][ ](Setup) to display the setup tabs.
Step 2: Use the [ , ] keys to highlight the System tab.
Step 3: Use the [ ] key to highlight 36DLP Output and [ , ]
to select between On and Off.
Step 4: Press [MEAS] to return to the Measure Mode.
4.7 High/Low Alarms (MG2-XT and
MG2-DL Only)
The High/Low alarm allows the user to establish high and low alarm
set points. When a thickness is displayed below the Low Alarm set
point or above the High Alarm set point, an audio beep is sounded and
an alarm flag is displayed.
When the alarm is active but not above or below set points, the gage
displays an “A”. The gage displays an “L” to indicate a Low Alarm
condition and an “H” to indicate a High Alarm condition only when
set points have been violated.
