910-257C March 2006
Page 4-8 MG2 Series
Waveform has been activated and the Waveform function has
been turned on. This feature allows the user to adjust the Gain,
Extended Blank and E1 (Echo 1) blank to select which pair of
backwall echoes is to be used for the measurement. For more
details, refer to Section 4.13.3.
To activate the Meas Option:
Step 1: Press [2ndF][ ](Setup) to display the setup tabs.
Step 2: Use the [ , ] to highlight the MEAS tab.
Step 3: Use the [ ] key to highlight Meas Option and [ , ] to
select Standard, Auto Echo-to-Echo, or Manual Echo-to-
Echo (Waveform Mode only).
Step 4: Press [MEAS] to return to the Measure Mode.
4.5.2 Units
Changing units allows the user to change from inch measurement
units to millimeter measurement units.
To change units:
Step 1: Press [2ndF][ ](Setup) to display the setup tabs.
Step 2: Use the [ , ] keys to highlight the MEAS tab.
Step 3: Use the [ ] key to highlight Units and the [ , ] keys
to select English (") or metric (mm).
Step 4: Press [MEAS] to return to the Measure Mode.
