910-257C March 2006
Page 4-10 MG2 Series
are displayed in filled-in form, and recalled max values are displayed
in outlined form. The maximum value is retained in a temporary
memory until a new maximum thickness value replaces it or until the
[Meas] key is pressed to reset the maximum. When Max Mode is
selected, the MG2 automatically changes to a 20 Hz fast update mode.
To select Min/Max:
Step 1: Press [2ndF][ ](Setup) to display the setup tabs.
Step 2: Use the [ , ] keys to highlight the MEAS tab.
Step 3: Use the [ ] key to highlight Min/Max and the [ , ]
keys to select among Off, Min, or Max.
Step 4: Press [MEAS] to return to the Measure Mode.
4.5.5 Hold/Blank
Hold/Blank controls:
• Hold: The gage holds the last measurement when no
measurements (LOS) are being made.
• Blank: The display blanks out the thickness value when no
measurements (LOS) are being made.
The MG2 Series is set by default to blank out the measurement
display when no measurements are being made. When Hold mode is
selected, live (active) thickness readings are displayed with filled-in
numbers and held measurements are displayed with outlined numbers.
To change Hold/Blank:
