Panametrics MG2 - Creating Files from a Computer; Creating Files from the MG2-DL

910-257C March 2006
Page 5-6 MG2 Series
To insert a character at the cursor position, do the following:
Press [CAL ZERO]. The character at the cursor and all those to the
right move one position to the right, making a space for a new
character.
To delete the character at the cursor position, do the following:
Press [CAL VEL]. The character at the cursor is deleted and any
characters to the right moves left one position to fill-in the empty
space.
5.3.2 Create Files From a Computer (Using
GageView)
See the GageView Interface Program Instruction Manual.
5.3.3 Create Files from the MG2-DL
To create files from the MG2-DL, follow these steps:
Step 1:Press [2
nd
F],[ ](FILE). The File Tab menu opens.
Step 2:Press [ ] and [ ] to highlight the Create option.
Step 3:Press [].
5.3.3.1 Incremental
After a starting ID number (up to 10 alphanumeric characters) has been
entered, the gage automatically increments to the subsequent ID
numbers using the following incrementing rules:
• Only that portion of an ID number consisting of digits and letters
(no punctuation marks) beginning with the right-most character
