910-257C March 2006
Page 5-4 MG2 Series
The allowable number of ID numbers within a file is dependent on the
total number of identifiers in the datalogger. There are no restrictions
on the use of any allowed character at any position in an ID number
except that you cannot use a space as either the first or last character of
the ID number.
5.3 Creating Data Files
You can create data files for the MG2-DL datalogger from within the
gage.
Throughout this section there are references to the use of the MG2-DL
Standard Editing Commands. These commands are described in the
section below.
5.3.1 Standard Editing Commands
To enter a character or a symbol at any character location, follow these
steps:
Step 1:Press [] or [] to select a letter, number, or punctuation mark.
Step 2:Press and quickly release a slewing key to change the character
by one value.
Hold down an arrow key to continuously cycle through the letters,
numbers, and punctuation marks until the desired character is
displayed.
The [ ] key moves forward from A to Z then *, #, :, ,, /, ., -, blank,
9, 8, 7, 6, 5, 4, 3, 2, 1, A, and so forth.
The [ ] key moves backward from 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, -, ., /, ,,
:, #, *, Z to A blank - and so forth.
