910-257C March 2006
Page 9-6 MG2 Series
Note: If PR TX displays N/A, then either the cable is broken or
there is a problem with the transducer.
SW REV Reports software version
(1.00/1.00G)
Battery Indicates current battery volt-
age
Probe Indicates current attached
probe
PR TX Indicates the time of flight for
the transmit delay line
PR RX Indicates the time of flight for
the receiver delay line
Table 9-2: DIAG2 Results
