910-257C March 2006
Page 3-12 MG2 Series
Step 1: From Measure mode, press [2
nd
F], [ ](SETUP).
Step 2: Use [ ] to highlight the Meas Option in the Meas tab.
Step 3: Use the [] and [] keys to change between Standard
and Auto Echo-to-Echo mode.
Step 4: Press [MEAS] to return to the Echo-to-Echo Measure
mode.
To calibrate the Echo-to-Echo feature:
Step 1: Zero the transducer by wiping the tip until dry and then
pressing [2
nd
F], [CAL ZERO](DO ZERO).
Step 2: Couple the transducer to a thick calibration standard that
does not exceed a thickness of 0.500” (12.5mm) and is
thicker than 0.100” (2.5mm) and press [CAL VEL].
Step 3: When the reading is stabilized, press [ENTER].
Step 4: Uncouple the transducer from the material and enter the
thickness of the block using the [
, , , and ]
slewing keys.
Step 5: Couple the transducer to a thin calibration standard but one
greater than 0.100” (2.5mm) and less than 0.500”
(12.5mm), and press [CAL ZERO].
Step 6: When the reading is stabilized, press [ENTER].
Step 7: Uncouple the transducer from the material and enter the
thickness of the block using the [
, , , and ]
slewing keys.
Step 8: Press [MEAS] to complete the calibration.
Note: The Echo-to-Echo measurement mode operates only
