March 2006 910-257C
MG2 Series Page 4-3
Additionally, when the backlight is switched on, you may select a
power-saver Auto Backlight mode, which turns the backlight on only
when a reading is being made and turns it off five seconds after LOS.
To select Auto Backlight:
Step 1: Press [2
nd
F], [ ](SETUP).
Step 2: Use [ ] to select the System Tab.
Step 3: Use the [ ] key to highlight Backlight Mode
Step 4: Use the [ ] and [ ] keys to change between Normal
and Auto.
Step 5: Press [MEAS] to return to the measure mode with the new
settings.
To adjust Contrast:
The Contrast adjustment feature allows the MG2 Series thickness
gages to adjust the contrast (light or dark) of the display.
To adjust the display contrast for the Model MG2 and MG2-XT:
Step 1: From Measure Mode, press [2
nd
F][Light Bulb](LCD ADJ).
Step 2: Use the [ ] or [ ] key to adjust contrast.
Step 3: Press [ENTER] to exit Contrast Adjust Mode.
