910-257C March 2006
Page 5-12 MG2 Series
key to enter a file name using the [ , , , ] editing
function. Press [ENTER].
Step 4: Use the [ and ] keys to select Sequential. Press
[ENTER].
Step 5: Use the [ and ] keys to select Normal or THRU
COAT
®
. Press [ENTER]. Normal is for standard files.
THRU COAT is used when storing THRU COAT thickness
readings.
Step 6: Use the [ and ] keys to select Continue. Press
[ENTER].
Step 7: Use the [ ] key to enter the Start ID# using the [ , ,
, ] editing function. Press [ENTER].
Step 8: Use the [ ] key to enter the End ID# using the [ , ,
, ] editing function. Press [ENTER].
Step 9: Use the [ and ] keys to select Done or Cancel. Press
[ENTER].
5.3.3.3 2-D Grid File
A 2-D grid is a sequence of ID numbers arranged to describe a path
through a two-dimensional matrix. Each part of the ID number
corresponds to a particular matrix dimension.
A 2-D (two-dimensional) sequence begins with the ID number that
refers to the first column and the first row. Then the column (or row)
increments one value at a time until the sequence reaches the last column
(or row) value while the other dimension value stays constant. At this
point the other dimension increments from its first to its last value. This
