Panasonic EBL128

Panasonic Eco Solutions Nordic AB
MEW01623 Rev: - EBL128 Operating Instructions V2.0.x
44
001 ZONE-ADDR 12-45 LAST ZONE 12 No. 01
"Alarm text for 12-45"
One zone (e.g. zone 14; a conventional zone line input)
001 ZONE 14 LAST ZONE 14 No. 01
"Alarm text for zone 14"
More than one alarm point in one zone (e.g. detectors 12-45 & -46)
001 ZONE-ADDR 12-45 LAST ZONE 12 No. 01
"Alarm text for 12-45"
The LEDs "Alarms queued" (L2) are indicating that more than one
alarm point is in alarm. Press the button "Alarms queued" (P1) to see
the other alarm:
002 ZONE-ADDR 12-46 LAST ZONE 12 No. 01
"Alarm text for 12-46"
One alarm point in two zones (e.g. detectors 12-45 & 13-02)
001 ZONE-ADDR 12-45 LAST ZONE 13 No. 02
"Alarm text for 12-45"
The LEDs "Alarms queued" (L2) are indicating that more than one
alarm point is in alarm. Press the button "Alarms queued" (P1) to see
the other alarm:
002 ZONE-ADDR 13-02 LAST ZONE 13 No. 02
"Alarm text for 13-02"
More than one alarm point / zone
LEDs "Alarms queued" (L2) are blinking (0.4 / 0.4 sec.), indicating
more than one fire alarm.
39
To scroll through the alarms, use the push
button "Scroll" (P1). The fire alarms are stored in a circular buffer
and when scrolling from the last to the first alarm, the LEDs "Alarms
queued" will be turned off for approx. three seconds.
When the "Scroll" button has been used the first alarm will be
automatically displayed again after 20 seconds.
If an ext. FBP 1826 with a built-in printer is connected, the printer
will print each fire alarm
40
, e.g.:
*** Fire Alarm ***
ZONE-ADDR: 12-45 Time HH.MM Date MM-DD
Alarm text for 12-45
39
Up to 256 alarms can be presented in the display. Alarm = ZONE and/or
ZONE-ADDRESS.
40
The alarms will be printed like they are presented in the display, i.e. as an
alarm point (ZZ-AA) or a zone (ZZ) and alarm text if programmed.
