9.29 PBX Configuration—[1-1]
Configuration—Slot—Card Property—E1 type
MFC-R2 Setting 1
ANI Service—Mode
Selects the ANI (Automatic Number Identification) service mode.
Value Range
None: ANI service is not activated.
Incoming call only: Receives the caller’s number from the E1 line.
Outgoing call only: Sends the caller’s number to the E1 line.
Both calls: Sends and receives the caller’s number through the E1 line.
Maintenance Console Location
9.29 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 1
ANI Service—ANI Max. digits
Specifies the maximum number of digits to be received via ANI when receiving a call with ANI.
Value Range
None, 1–16
Maintenance Console Location
9.29 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 1
MFC-R2 Timer—Forward
Specifies the maximum time that the PBX waits for an MFC-R2 forward signal sent from the telephone
company.
Value Range
1–30 s
Maintenance Console Location
9.29 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 1
MFC-R2 Timer—Backward
Specifies the maximum time that the PBX waits for an MFC-R2 backward signal sent from the telephone
company.
Value Range
1–30 s
PC Programming Manual 397
9.29 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 1
