Panasonic KX-NS500 - PBX Configuration-[4-1-7] Extension-Wired Extension-CLIP ID Table

12.1.7 PBX Configuration—[4-1-7] Extension—Wired
Extension—CLIP ID Table
Up to 8 CLIP IDs can be set for each wired extension.
Extension Number
Indicates the extension number of the extension (reference only).
Value Range
Max. 5 digits (consisting of 0–9)
Maintenance Console Location
12.1.7 PBX Configuration—[4-1-7] Extension—Wired Extension—CLIP ID Table
Extension Name
Indicates the name of the extension (reference only).
Value Range
Max. 20 characters
Maintenance Console Location
12.1.7 PBX Configuration—[4-1-7] Extension—Wired Extension—CLIP ID Table
CLIP 1–8
Specifies up to 8 CLIP IDs for the extension.
Value Range
Max. 16 digits (consisting of 0–9, *, and #)
Maintenance Console Location
12.1.7 PBX Configuration—[4-1-7] Extension—Wired Extension—CLIP ID Table
PC Programming Manual 677
12.1.7 PBX Configuration—[4-1-7] Extension—Wired Extension—CLIP ID Table
