243
Setting Inspection Conditions
Chapter 4
INDEX
Item
Condition for OK judgement
Checker - Connector Gray
Window (CGW) No.0-999
Judgement (JUDGE)
Individual
Judgement(PJUDGE) No.0-99
Checker - Connector Gray
Edge (CGE) No.0-999
Judgement (JUDGE)
Pitch Total Judgement and Distance Difference
Total Judgement are both OK.
Pitch total judgement
(PTJUDG)
Pitch Judgements are all OK.
Distance Difference Total
Judgement (UTJUDG)
Distance Difference Judgements are all OK.
Pitch Judgement(PJUDGE)
No.0-99
(Judgement of each pitch)
The detected pitches are within the Judgement
limits of pitches.
Distance Difference
Judgement(UJUDGE) No.0-99
(Judgement of each distance
difference)
The detected distance difference is within the
Judgement limits of distance difference.
Smart Edge (Circle) (SEC)
No.0-999
Judgement (JUDGE)
The judgements of Measurement Value, Standard
Deviation, Circularity and Unused Edge Count are
all OK.
Measurement Judgement
(LJUDGE)
Measurement Value*1) is within the range of the
maximum/minimum limitations.
Standard Devation Judgement
(SJUDGE)
Standard Deviation is within the range of the
maximum/minimum limitations.
Circularity Judgement
(CJUDGE)
Circularity is within the range of the
maximum/minimum limitations.
Unused Edge Count
Judgement (FJUDGE)
Unused Edge Count is within the range of the
maximum/minimum limitations.
Individual Judgement
(IJUDGE) No.0-3599
The result of the cell with the specified No. is OK.
(Undetected, excluded and NG cells are NG.)
Smart Edge (Line) (SEL)
No.0-999
Judgement (JUDGE)
The judgements of Measurement Value, Standard
Deviation, Linearity and Unused Edge Count are
all OK.
Measurement Judgement
(LJUDGE)
Measurement Value*2) is within the range of the
maximum/minimum limitations.
Standard Devation Judgement
(SJUDGE)
Standard Deviation is within the range of the
maximum/minimum limitations.
Linearity Judgement (JUDGE)
Linearity is within the range of the
maximum/minimum limitations.
Unused Edge Count
Judgement (FJUDGE)
Unused Edge Count is within the range of the
maximum/minimum limitations.
Individual Judgement
(IJUDGE) No.0-3599
The result of the cell with the specified No. is OK.
(Undetected, excluded and NG cells are NG.)
Geometry Calculation
(GGC) No.0-999
Judgement (JUDGE)
All the judgements for the items set in Judgement
Limits are OK.
X Judgement (XJUDGE)
IP X or Center X is within the range of the
maximum/minimum limitations.
Y Judgement (YJUDGE)
IP Y or Center Y is within the range of the
maximum/minimum limitations.
Standard Deviation
Judgement (SJUDGE)
Standard Deviation is within the range of the
maximum/minimum limitations.
Angle Judgement (AJUDGE)
Line Angle is within the range of the
maximum/minimum limitations.
Distance Judgement
(DJUDGE)
Distance is within the range of the
maximum/minimum limitations.
*1) Measurement Value = Radius, Diameter or Width (decided according to the setting value of Detect Mode)
*2) Measurement Value = Deviation, Distance or Width (decided according to the setting value of Detect Mode)
