244
Setting Inspection Conditions
Chapter 4
Item
Condition for OK judgement
Geometry Calculation
(GGC) No.0-999
Intersecting Angle Judgement
(CAJUDGE)
Intersecting Angle is within the range of the
maximum/minimum limitations.
Radius Judgement (RJUDGE)
Radius is within the range of the
maximum/minimum limitations.
Major Axis Judgement
(LAJUDGE)
Major Axis of Ellipse is within the range of the
maximum/minimum limitations.
Minor Axis Judgement
(SAJUDGE)
Minor Axis of Ellipse is within the range of the
maximum/minimum limitations.
Numerical Calculation
(CAC/OCA)
CAC Numerical Calculation
(JUDGE) No.0-999
Calculation result is within the Judgement limits.
OCA Numerical Calculation
Previous Result (JUDGE)
No.0-999
Judgement (JRC/JDC)
JRC Judgement (JUDGE)
No.0-999
Judgement formula returns true.
JDC Judgement (JUDGE)
No.0-999
