Setting Inspection Conditions
Chapter 4
INDEX
Example of Output Data Assignment
Scan Count, Judgement, and Numerical Calculation output with Bit Data: 32-bit and Bit Width: 16-bit
Scan Count = 100, Judgement=JDC000-14(15 points), Numerical Calculation CAC000=70000
OUT
15
OUT
14
OUT
13
OUT
12
OUT
11
OUT
10
OUT
9
OUT
8
OUT
7
OUT
6
OUT
5
OUT
4
OUT
3
OUT
2
OUT
1
OUT
0
1st (Lower 16 bits of Scan Count)
0 0 0 0 0 0 0 0 0 1 1 0 0 1 0 0
2nd (Higher 16 bits of Scan Count)
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
3rd (Judgement 0-14)
0
JDC
014
JDC
013
JDC
012
JDC
011
JDC
010
JDC
009
JDC
008
JDC
007
JDC
006
JDC
005
JDC
004
JDC
003
JDC
002
JDC
001
JDC
000
4th (Lower 16 bits of CAC000)
0 0 0 1 0 0 0 1 0 1 1 1 0 0 0 0
5th (Higher 16 bits of CAC000)
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
