Control with Communication Port
Details of Read out/write Command Parameter
When writing maximum and minimum values in sets using %PWP command, specify maximum values in
Data 1 and minimum values in Data 2. When reading two data in sets using %PRP command, the data is
output in the same order.
System values
upper limit, 10000.00 is
0: RUN menu,
1: SETUP menu
(4-digit of year/ 2-digit
of Month/ 2-digit of
(2-digit of Hour:
2-dgit of Minute:
to System Register
available after decimal
Slice Level
The symbol of “?” shown in parameters is a slice level group (A - Z)
Maximum and
Minimum values
Data 1 = Min.
Data 2 = Max.
Checker
The symbol of “nnn” shown in parameters is a checker number (000 - 999).
Max. and Min. No. of
Pixels.
Data 1 = Min.
Data 2 = Max.
Max. and Min. No. of
Objects
Data 1 = Min.
Data 2 = Max.
Data 1 = Min.
Data 2 = Max.
