AS-i EtherNet/IP Gateway
Appendix: the first commissioning of AS-i
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 24.4.2007
145
The addresses of all detected slaves are now displayed sequentially.
Switch to the protected operating
mode and store the AS-i configuration.
Leave the configuration mode by
pressing the “mode” button for at least
five seconds until the “prj mode” LED
goes out.
The configuration of the AS-i master is now finished.
What to do ? How to go about it?
