Peri Trio - Shaft with two Shaft Corners TRIO; Shaft with four Shaft Corners TRIO

69
Shaft with four
Shaft Corners TRIO
The striking dimensions are reduced
by 35 mm on each side of the shaft.
(Fig. A17.07)
shuttered
struck
Abb. A17.07
10 cm
20 cm
35 mm
35 mm
Fig. A17.0 6
shuttered
struck
10 cm
20 cm
17.5 mm
17.5 mm
There are two possibilities for
constructing a shaft:
 With two Shaft Corners TRIO
 With four Shaft Corners TRIO
The option to be used is project-specifi-
cally determined. It depends on:
 the striking clearance
 the weight per shaft and
 the number of nails for box-outs of
individual components, e.g. for
windows and doors.
Shaft with two
Shaft Corners TRIO
The striking dimensions are reduced
by 17.5 mm on each side of the shaft.
(Fig. A17.06)
A17 Shaft formwork
TRIO Panel Formwork
Instructions for Assembly and Use – Standard Configuration
