Wall thicknesses
Dimensions in the illustrations of the
wall thicknesses (WD) are given in mm.
Wall thickness 150
(Fig. A17.08a + A17.08b)
Wall thickness 200
(Fig. A17.09a + A17.09b)
Wall thickness 250
(Fig. A17.10a + A17.10b)
Shaft with
two Shaft Corners TRIO
Shaft with
four Shaft Corners TRIO
A17 Shaft formwork
TRIO Panel Formwork
Instructions for Assembly and Use – Standard Configuration
Fig. A17.0 8a
Fig. A17.0 8b
Fig. A17.0 9a
Fig. A17.0 9b
Fig. A17.10a
Fig. A17.10b
