4
HD11 XE Getting Started
4535 612 62651
101
Using the System
➤ To connect a plain-paper printer
1. Make sure that the printer is authorized by Philips and that you have obtained
a COTS CD-ROM from your Philips-qualified service representative.
NOTE
You will only need the COTS CD-ROM if your system does not already support
the printer you purchased.
CAUTION
Do not attempt to use the installation CD-ROM provided by the printer manufac-
turer. Doing so could cause conflicts with the operating system and render it
inoperable. Instead, use the COTS CD-ROM provided by your Philips-qualified
service representative.
2. Turn off the system and unplug the power cord from the power source.
3. Connect the printer’s USB cable into the back of the printer, and plug the
other end into the system.
4. Connect the printer’s power cord into the back of the printer, and plug the
other end into an appropriate power source.
ARNINGS
• If you use peripheral equipment powered from an electrical source other than
the ultrasound system, the combination of the peripheral equipment and the
ultrasound system is considered to be a medical system. It is your responsibil-
ity to comply with IEC 60601-1-1 and to test the medical system according to
the requirements. If you have questions, contact your Philips representative.
• Do not use nonmedical peripherals within 1.5 m (6 ft) of a patient, unless the
nonmedical peripherals receive power from an isolated power outlet on the
Philips ultrasound system, or from an isolation transformer that meets medi-
cal safety standards, as defined by standard IEC 60601-1-1.
5. Reconnect the system’s power cord to the power source.
6. Turn on the plain-paper printer, and then turn on the system.
For information on assigning a record key, see “Assigning Keys to Peripherals” on
page 103.
