Phoenix Contact RAD-900-DAIO6

Addressing I/O extension modules and RAD-900-DAIO6 with Modbus RTU
3827_en_B PHOENIX CONTACT 99/138
9.4 Module type and error code register
You can read the module type and data currentness of the I/O extension modules from the
registers 30xx0 and 40xx0.
Table 9-3 Module type and currentness of data
The individual I/O extension modules can be clearly distinguished by the module type. The
module type ID of the extension module can be read in the Modbus register.
Table 9-4 Module type IDs
“Module type” register value
If the module type in the register is invalid or unavailable, then the register value is 0.
“Currentness of data” register value
If the data in the register is not up-to-date, the register value is 1. This is, for example, the
case if the wireless connection to an input module fails. The input process data is then re-
tained in the Modbus table, but is no longer updated. In the case of an output module, the
“Currentness of data” register value is set to 1 until the output process data has been written
to the Modbus registers.
The read I/O data is only valid and current if a valid module type value is returned by the
slave and the “Currentness of data” register value equals 0.
30xx0, 40xx0
1
1
xx = I/O-MAP address set using the thumbwheel
Module type and currentness of data
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
X
2
2
X = Currentness of data, bit 8
Module type
Module type Order No. Module type ID
Analog inputs
RAD-AI4-IFS 2901537 20
hex
RAD-PT100-4-IFS 2904035 21
hex
Analog outputs
RAD-AO4-IFS 2901538 30
hex
Digital inputs
RAD-DI4-IFS 2901535 01
hex
RAD-DI8-IFS 2901539 02
hex
(static mode)
40
hex
(pulse counter mode)
Digital outputs
RAD-DOR4-IFS 2901536 10
hex
RAD-DO8-IFS 2902811 11
hex
Analog/digital inputs and outputs
RAD-DAIO6-IFS 2901533 60
hex
RAD-900-DAIO6 2702877 60
hex
